Semi-Auto Stencil Printer

Model: Semi-Automatic Stencil Printer
Brief: SMT, Semi-Auto Stencil Printer, Semi-Auto Stencil Printer, lead-free reflow oven, reflow soldering, wave soldering, SMT equipment, stencil printer, AOI,  wave soldering machines, solder paste, fluxes, Bar Solder, semi-automatic printer, solder paste,



Conveyor
Model: Linkage/Inspection Conveyor
Brief: SMT, Linkage, SMT Conveyor, SMT Linkage, SMT Inspection Conveyor
Details
> Second-ranking double rack/gear adjustable wide organization, ensure transportation guide mutual parallel;
> Machine adopts professional wear-resisting anti-static belts, special aluminum guide rail, ensure smooth shuttle smooth, transportation;
> Second-ranking communication structure, equipped with signal standard with other equipment shuttle; Online
> Second-ranking optional standard fixtures and process card board, optional protect edge for aluminum or anti-static counter.

Details
>Using precision guide rail and the import motor to drive the blade seat conversion, printing, and high accuracy.
>Printing scraper can rotate 45 degrees fixed up, easy printing stencil and squeegee cleaning and replacement.
>Combined with a fixed groove printing platen and PIN, easy installation and adjustment, for single, double sided printing.
>School Edition way to move a steel mesh, combined with printed (PCB), X, Y, Z. Convenient fine adjustment.
>Can be set to one-way and two-way, a variety of printing methods.
>With the automatic counting function to facilitate the production of output statistics.
>Printing speed display, can be adjusted.



SPECIFICATION
Specifications P-300 Semi-auto SMT Stencil Printer
Dimensions900*8900*1580mm
Weight300kg
Power SupplyAC220V± 10%, Single Phose 50/60Hz,
Air Pressure4.5-6Kg/cm
Power Consumption3KW
Transport SpeedStepping Motor, 0-1500mm/s Programmable
PCB Printing Size50*50-400*340mm
PCB Thickness0.2-6mm
Stencil Size420mm*380mm-550mm*650mm
Stencil PositioningAutomatic Automatic
Cycle Time<9S
Accuracy± 0.05mm
Repeating Accuracy± 0.01mm

SPECIFICATION
Specifications Conveyor
General
Outside Dimension(L*W*H)800/1000/1200/1500X750X900mm
Electric Supply Required2phase, 220V 50/60Hz
WeightApprox. 100KG
Converyor Speed Range300~2000mm/min
Power Consumption0.5KW
Max. Width Of PCB300mm (Option: 410mm )
Converyor Height900+/-20mm
Fixed Rail Side(With Rail)Front Rail Fixed(Option: Rear Rail Fixed)
