Signal System | NTSC / PAL |
Image Sensor | 1/3"Sony SUPER HAD CCD, Powerful DSP (811/810 AK+ EFFIO-E ) |
Sync. System | Internal |
Effective Pixels Number | NTSC : 976(H)x 494(V) PAL: 976(H)582(V) |
Horizontal Resolution | 700 TV Lines (BW 730TV Lines) |
Video Output Level | 1.0 Vp-p (75, Composite) |
S/N Ratio | More than 52dB (AGC Off) |
LED | 72 pcs (IR Distance 60-70 Meters) |
Lens | 2.8-12 mm lens (9-22 mm lens is optional) |
Min. Illumination | 0 lux when IR on |
Day & Night | AUTO / COLOR / B/W / EXT1/ EXT2 |
D/N delay | 0~255s Adjustable |
Backlight | BLC / HLC / OFF |
Auto Gain Control | Adjustable |
White Balance | ATW / PUSH / USER1 / USER2 / ANTI CR/ MANUAL / PUSH LOCK |
Electronic Shutter Speed | 1/50 ~ 1/10,000sec |
ATR ((Adaptive Tone Reproduction) | ON/OFF |
Noise Reduction | 2D-DNR (Y/C, Y, C, OFF) |
Mirror | ON/OFF |
Motion Detection | ON / OFF;(4 Zones) |
Block Display | ON/OFF |
Privacy Mask | ON/OFF; (8 Zones) |
Mirror | ON/OFF |
Power Voltage | 12V DC |
Weight (Goss Weight) | Approx. 0.8 kg with bracket |
