CONTINUOUS PASSIVE MOTION UNIT "VISHESH" Shoulder):

Product Description

Shoulder CPM (Model-VISHESH) is a micro-computer controlled unit that represents the latest breakthrough In CPM technology. Solid state circuitry control panel with highly visual LED Digital readouts allows passive motions of shoulder joint through prefixed Range of Motion and Time. Unit is fitted on electrical Jack to adjust height according to patient's requirement. Comes with all accessories.

TECHNICAL SPECIFICATION:
* Therapy Modes: Intermittent and Progressive passive movements.
* Pause Time: Programmable Extension/Flexion Pauses from 00 to 99 seconds.
* Treatment Time: Programmable from 01 to 99 min.
* Inching Switch: Starting position can be set according to the need of patient.
* Memory/Programme: 80 Pre-set treatment patterns are stored in memory.
* Open Proggramm: 20 programes are Free to store your own patterns.
* Displays: Digital display of ROM settings Pause Time, Treatment Time
* ROM Setting: Programmable from 00 to 180deg. and -90 to +90 degrees for all Shoulder movements.
* Height Adjustment: Electrically, by Push button switches.
* Arm Settings: Right or Left arm can be set & exercised by little adjustments.
* Patient Safety: Patient can stop / Interrupt treatment with hand held switch.
* Power Supply: 200-240 V AC at 50-60 Hz.
